Model: CBM160

Total weight: 3500kg

Worktable dimension: 1600mm

Overall size: 4000*3500mm

working airpressure: 0.7Mpa

voltage: 380V（3 phase 4 wire）

main motor power: 5.5kw

feeding driving power: 1.1kw

sawblade lift height: ≤60mm

cutting length: 1600mm

feeding length: 2200mm

cutting speed: 0-50m/min

feeding speed: 0-30m/min

cutting linear precision: ±0.15mm

driving movement type: servo driving

cutting movement type: servo driving
