Name
Single drill unit + tool box
Single drill unit
Double drill unit + tool box
Double drill unit
Model
612T
612
612BT
612B
Dimension
5500*2750*2300mm
Total power
22KW
23.5KW
21KW
Total weight
3000KG
3700KG
3500KG
Workpiece length
150-3050mm
Workpiece width
35-1200mm
Workpiece thickness
10-60mm
X/Y/Z axes moving speed
150/100/45m/min
Drill unit
Upward vertical drilling：
9 pieces
9 pieces*2
Horizontal drilling：
8 pieces
8 pieces*2
Downward vertical drilling：
Drill unit power
2.2KW*2
2.2KW*3
Milling spindle way
Er3
Milling spindle speed
18000r/min
Milling spindle power
Tool-changing spindle: 6 kW; milling spindle: 3.5 kW
Milling spindle: 3.5 kW*2
Tool changing tool box
Tool box capacity
4 knives
/
Worktable height
900mm
Dust collect diameter
200mm,100mm
Voltage
380V 50Hz
Air pressure
0.6-0.8MPa
