Simple operation with high cutting precision;

optional manual clamping device available.

Supports cutting of various materials including angle rulers, multi-layer boards, particle boards, plywood, eco-board, OSB, solid wood boards, MDF, aluminum alloy boards, and more.

Standard cutting capacities: up to 2.65 m for 2.8 m machines; up to 2.85 m for 3 m machines; up to 3.05 m for 3.2 m machines.

Operates smoothly with a clean, edge-free cutting surface. Features a suspended frame design, ensuring stable, efficient, and precise performance.

manual type operation for up&down and tilt the sawblade.

Mail us for more informations.

We prefre OEM orders and accept customization.

Model：HZ3200M

Cutting length：3150mm

Main motor power：5.5KW

Total power：6.6KW

Total weight：700kg

Machine dimenstion：3050*3150*900mm

Max. cutting depth：70mm

Dia. of main sawblade：300mm

Dia. of scoring sawblade：120mm

Rotary speed of main saw：4000-6000r/min

Rotary speed of scoring saw：8000r/mim

Power of scoring saw：1.1kw

Cutting angle：0-45°
